Cable/Pipe locator

Pipeline detection (cable position tracking, direction display, depth measurement, current measurement), cable identification, A word frame fault search (optional function)

  • 1
  • mrp 2
  • 50.00% off

When using the coupling method and the induction method, the transmitter will produce interference in close distance. The distance of interference is related to the transmission power and frequency. The greater the power, the higher the frequency, the stronger the interference.

The minimum distance of the receiver without disturbed by the transmitter often needs to be determined by test:

Pipeline detection: 5m away, 20m away as no interference Cable identification: the coupling method beyond 2~5m can be confirmed as no interference

    • Transmitter clamp inner diameter:φ125mm
    • Power:8.4V large capacity rechargeable lithium battery
    • cable length of transmitter clamp:3M
    • Sound instructions:FM tone with signal intensity
    • Pipeline measurement depth:0-20m
    • Touch screen:yes
